We are an integrated manufacturer for research and develop, production and sales of pelletizing machine .

All detailed technical parameter of pellet mill

We have all kings of pellet mill,including wood pellet mill and feed pellet mill.And for wood pellet making ,we have flat pellet mill (flat diesel pellet mill and flat electric pellet mill) and ring die pellet mill (always used by factory for industry runs by generator system );for feed pellet mill ,above pellet making machine all can deal with the animal feed,but the inner structure of pellet mill are different.

The detailed technical parameter of pellet mill :

Type	Motor	NW/GW(kg)	dimemsion(cm）
DY120A	7.5HP gasoline engine	80/100	76*43*71
DY120A	8HP diesel engine	120/140	87*44*73
DY120B	2.2kw Single-phase machine 3kw Three-phase machine	80/100	75*32*61
DY120C	2.2kw Single-phase machine 3kw Three-phase machine	80/100	75*35*65
DY120P	PTO Axis rotation	70/90	76*42*71
DY150A	7.5HP gasoline engine	95/115	76*43*71
DY150A	13HP gasoline engine	95/115	76*43*71
DY150A	8HP gasoline engine	120/140	87*46*73
DY150B	4kw Three-phase machine	95/115	75*35*65
DY150C	4kw Three-phase machine	95/115	75*35*65
DY150P	PTO Axis rotation	90/100	76*72*71
DY200A	15HP gasoline engine	280/310	118*56*95
DY200B	7.5kw Three-phase machine	200/230	100*43*95
DY200C	7.5kw Three-phase machine	200/230	100*46*90
DY200P	PTO Axis rotation	140/160	77*56*102
DY230A	22HP diesel engine	280/310	118*56*95
DY230B	11kw Three-phase machine	290/320	114*47*97
DY230C	11kw Three-phase machine	290/320	114*54*93
DY230P	PTO Axis rotation	150/180	77*56*102
DY260A	35HP diesel engine	450/480	184*70*116
DY260B	15kw Three-phase machine	330/360	120*52*107
DY260C	15kw Three-phase machine	330/360	122*53*107
DY260P	PTO Axis rotation	200/230	77*56*115
DY300A	55HP diesel engine	520/560	220*60*123
DY300B	22kw Three-phase machine	410/450	127*52*107
DY300C	22kw Three-phase machine	410/450	128*58*105
DY300P	PTO Axis rotation	260/290	77*56*115
DY360A	55HP diesel engine	600/620	227*62*126
DY360C	22kw Three-phase machine	470/500	134*58*106
DY360P	PTO Axis rotation	300/330	87*85*116
DY400A	55HP diesel engine	750/780	227*62*126
DY400C	30kw Three-phase machine	630/660	145*62*115
DY400P	PTO Axis rotation	400/420	87*85*116
MDY225	7.5kw Three-phase machine	230/260	100*45*98
MDY225B	7.5kw Three-phase machine	230/260	100*46*115
MDY225C	7.5kw Three-phase machine	320/360	100*46*115
MDY225A	15HP diesel engine	310/320	118*56*95
MDY229A	22HP diesel engine	310/320	118*56*95
MDY229B	11kw Three-phase machine	320/360	110*48*118
MDY229C	11kw Three-phase machine	320/360	110*48*118
MDY229	11kw Three-phase machine	320/360	102*48*98
MDY295C	15kw Three-phase machine	520/540	123*54*121
MDY295	15kw Three-phase machine	450/480	108*52*105
MDY335	22kw Three-phase machine	580/600	134*60*121
MDY395	30kw Three-phase machine	620/650	152*60*121
MDY40-37	37kw Three-phase machine	1500/1600	164*65*174
MDY40-45	45kw Three-phase machine	1900/2000	185*74*174
MDY45-55	55kw Three-phase machine	3000/3100	242*121*195
MDY45-75	75kw Three-phase machine	3200/3300	252*121*200
MDY45-90	90kw Three-phase machine	3500/3600	278*132*210
CF158	2.2kw Single-phase machine 2.2kw Three-phase machine	75/95	48*58*63
CF198	7.5HP gasoline engine	120/140	96*62*105
CF198	4kw  Machine	120/140	90*58*102
CF420B	7.5kw Three-phase machine	260/320	112*82*107

---
